Sound Beats and Sine Waves Gizmo – Answer Key

Understanding how sound beats form and how sine waves interact is a cornerstone of introductory physics and music technology. The Sound Beats and Sine Waves Gizmo (developed by ExploreLearning) lets students visualize the superposition of two simple harmonic motions, hear the resulting beat pattern, and explore the mathematical relationships behind them. Plus, below is a comprehensive answer key that covers every interactive element of the Gizmo, explains the underlying concepts, and provides step‑by‑step solutions to the built‑in questions. Use this guide to verify lab results, prepare quizzes, or deepen your own grasp of wave interference Easy to understand, harder to ignore..

1. Introduction to the Gizmo

The Gizmo displays two sine‑wave generators (Wave A and Wave B) that can be adjusted independently for:

• Amplitude (A) – height of the wave (units: arbitrary, often “units”).
• Frequency (f) – number of cycles per second (Hz).
• Phase (ϕ) – horizontal shift (degrees or radians).

A third panel shows the resultant wave, which is the algebraic sum of the two input waves, and an audio player lets you hear the sound. The beat frequency appears as a periodic variation in loudness when the two frequencies are close but not identical The details matter here..

Not obvious, but once you see it — you'll see it everywhere.

2. Core Concepts Tested by the Gizmo

3. Answer Key for the Built‑In Questions

Below each question is the correct numeric answer (rounded to two decimal places when appropriate) followed by a concise explanation that you can copy into lab reports.

Question 1 – Basic Frequency Matching

Prompt: Set Wave A to 440 Hz and Wave B to 442 Hz. What is the beat frequency you hear?

Answer: 2.00 Hz

Explanation: Beat frequency = |440 – 442| = 2 Hz. The envelope will rise and fall twice per second, which you can verify by counting the “pulses” in the audio playback.

Question 2 – Amplitude Effect

Prompt: With both frequencies at 500 Hz, increase the amplitude of Wave A to 5 units and Wave B to 2 units. What is the maximum amplitude of the resultant wave?

Answer: 7.00 units

Explanation: When the two sine waves are in phase (default ϕ = 0°), amplitudes add linearly: 5 + 2 = 7. The resulting wave’s peak reaches 7 units.

Question 3 – Phase Shift to Achieve Destructive Interference

Prompt: Keep both waves at 600 Hz and amplitude 3 units. Adjust the phase of Wave B until the resultant amplitude is zero. What phase shift did you apply?

Answer: 180° (or π rad)

Explanation: A phase difference of 180° makes the two waves exactly opposite at every instant, causing complete cancellation: y₁ + y₂ = 0.

Question 4 – Calculating the Envelope Frequency

Prompt: Wave A = 1000 Hz, Wave B = 1005 Hz. What is the frequency of the envelope (the “beat” modulation) shown in the resultant wave graph?

Answer: 5.00 Hz

Explanation: Envelope frequency = |f₁ – f₂| = 5 Hz. The envelope’s cosine term oscillates at half the beat frequency, but the audible beat rate is 5 Hz Not complicated — just consistent..

Question 5 – Determining the Resultant Frequency

Prompt: If the two input frequencies are 250 Hz and 260 Hz, what is the average frequency of the resultant wave (the carrier frequency)?

Answer: 255.00 Hz

Explanation: The carrier frequency is the mean of the two: (250 + 260)/2 = 255 Hz. The resultant wave can be expressed as 2A cos(πΔf t) sin(2πf̄ t), where Δf = 10 Hz and f̄ = 255 Hz.

Question 6 – Changing the Sampling Rate

Prompt: The Gizmo’s audio playback uses a sampling rate of 44,100 samples/s. If you halve the sampling rate, what audible effect will you notice?

Answer: The sound will become distorted and lower in pitch (aliasing).

Explanation: Nyquist theorem requires the sampling rate to be at least twice the highest frequency component. Halving the rate reduces the Nyquist limit to 22,050 Hz, causing frequencies above this to fold back, producing audible artifacts Practical, not theoretical..

Question 7 – Visualizing Phase Difference

Prompt: Set both frequencies to 400 Hz, amplitudes to 4 units, and slide the phase control to 90°. Describe the shape of the resultant wave.

Answer: The resultant wave is a sinusoid with the same frequency (400 Hz) but its amplitude is √(A₁² + A₂² + 2A₁A₂ cos ϕ) = 5.66 units, and it is phase‑shifted relative to Wave A.

Explanation: Using vector addition of phasors:
Resultant amplitude = √(4² + 4² + 2·4·4·cos 90°) = √(32) ≈ 5.66. The waveform is still a pure sine at 400 Hz, but its peak occurs a quarter‑cycle later than Wave A Surprisingly effective..

Question 8 – Beat Perception Threshold

Prompt: At what maximum beat frequency can a typical human listener still perceive distinct beats? (Assume average adult hearing.)

Answer: ≈ 10 Hz

Explanation: Beats above ~10 Hz blend into a continuous tone, whereas lower rates are perceived as rhythmic pulsations. This threshold varies with individual hearing and loudness Easy to understand, harder to ignore..

Question 9 – Mathematical Derivation Check

Prompt: Write the expression for the resultant wave when Wave A = A sin(2πf₁t) and Wave B = A sin(2πf₂t).

Answer: y(t) = 2A cos[π(f₁ – f₂)t] sin[π(f₁ + f₂)t]

Explanation: Apply the trigonometric identity sin α + sin β = 2 cos[(α – β)/2] sin[(α + β)/2].

Question 10 – Real‑World Application

Prompt: Which musical instrument commonly uses beat frequencies to tune itself, and why?

Answer: The piano (or stringed instruments such as the violin).

Explanation: When two strings are tuned to the same pitch, the beats disappear, indicating that the frequencies are matched. Piano tuners listen for the slowing of beats as they adjust the tension.

4. Step‑by‑Step Lab Procedure (Optional)

If you need to replicate the Gizmo experiment in a classroom, follow these steps:

1. Open the Gizmo and reset all sliders to their default positions (Amplitude = 1, Frequency = 440 Hz, Phase = 0°).
2. Record the baseline waveform (single sine wave) by disabling Wave B.
3. Activate Wave B and set its frequency to 442 Hz. Observe the beat envelope and count the beats for 10 seconds → verify 2 Hz.
4. Change amplitudes to 5 and 2 units respectively; note the new peak amplitude (7 units).
5. Introduce a phase shift of 180° while keeping frequencies equal; the resultant graph should flatten to the horizontal axis.
6. Experiment with larger frequency separations (e.g., 1000 Hz vs. 1010 Hz) to see the envelope slow down, confirming the beat‑frequency formula.
7. Export the data (CSV) for each configuration to plot beat period vs. frequency difference in Excel or Google Sheets.

5. Scientific Explanation Behind Beats

When two sinusoidal waves of close frequencies travel through the same medium, their instantaneous displacement adds algebraically:

[ y(t) = A\sin(2\pi f_1 t) + A\sin(2\pi f_2 t) ]

Using the sum‑to‑product identity:

[ y(t) = 2A\cos\big[\pi(f_1-f_2)t\big]\sin\big[\pi(f_1+f_2)t\big] ]

• The carrier term, (\sin[\pi(f_1+f_2)t]), oscillates at the average frequency ((f_1+f_2)/2).
• The envelope term, (\cos[\pi(f_1-f_2)t]), modulates the amplitude at a rate equal to half the difference frequency. Because the envelope reaches a maximum twice per cycle, the audible beat frequency is (|f_1-f_2|).

Physically, the constructive interference (loud peaks) occurs when the two waves are in phase, and destructive interference (soft troughs) when they are out of phase. The human ear perceives the alternating loud‑soft pattern as beats Worth keeping that in mind..

6. Frequently Asked Questions (FAQ)

Q1: Why does the Gizmo display the envelope at half the beat frequency?
A: Mathematically the cosine envelope has frequency ((f_1-f_2)/2). On the flip side, each full cosine cycle produces two amplitude maxima (one positive, one negative), which the ear interprets as two beats, giving the audible beat frequency (|f_1-f_2|) Simple as that..

Q2: Can beats occur with non‑sinusoidal waves?
A: Yes, any periodic waveform can be decomposed into sine components (Fourier series). If two complex tones share many harmonic components with slightly different frequencies, each pair will generate beats, producing a richer “chorus” effect.

Q3: Does phase affect beat frequency?
A: No. Beat frequency depends solely on the absolute difference of the two frequencies. Phase only shifts the timing of the first beat.

Q4: How does temperature affect the speed of sound and therefore beats?
A: The speed of sound (v = \sqrt{\gamma RT/M}) changes with temperature, altering the wavelength for a given frequency. In a fixed‑length resonator, the frequency shifts, which can modify the beat rate if one source remains constant.

Q5: Why do we hear a “wah‑wah” effect in guitar distortion pedals?
A: Many distortion circuits intentionally modulate the phase or introduce slight frequency variations, creating rapid beats that our brain interprets as a sweeping tonal change.

7. Extending the Exploration

• Three‑Wave Interference: Add a third sine wave (Wave C) and investigate beat clusters when two frequency differences are similar (e.g., 440 Hz, 442 Hz, 444 Hz).
• Amplitude Modulation (AM) Analogy: Treat Wave A as a carrier and Wave B as a modulating signal; the resulting envelope mimics AM radio transmission.
• Real‑World Data Comparison: Record the sound of two tuning forks with a smartphone, perform a Fourier transform, and compare the measured beat frequency to the Gizmo’s prediction.

8. Conclusion

The Sound Beats and Sine Waves Gizmo offers a visual and auditory playground for mastering wave superposition, beat formation, and phase relationships. In practice, by following the answer key above, students can confidently validate their observations, solidify the mathematical foundations, and connect theory to musical practice. Whether you are preparing a lab report, designing a quiz, or simply satisfying curiosity, the concepts explored here—beat frequency = |f₁ – f₂|, constructive/destructive interference, and the carrier‑envelope representation—remain essential tools in physics, engineering, and the arts. Use the provided explanations to reinforce learning, spark discussion, and inspire further experimentation beyond the digital sandbox.
