9.2.6 Lab: Analyze a DDoS Attack – A Step‑by‑Step Guide

Understanding how distributed denial‑of‑service (DDoS) attacks work is essential for anyone studying network security, incident response, or ethical hacking. Lab 9.2.6 walks you through the process of capturing, examining, and interpreting traffic generated during a simulated DDoS event. By the end of this exercise you will be able to recognize the hallmarks of a volumetric attack, identify the tools commonly used by attackers, and apply basic mitigation concepts.

Why This Lab Matters

DDoS attacks remain one of the most prevalent threats to online services. They overwhelm a target’s bandwidth, CPU, or application resources, rendering legitimate traffic unusable. The 9.2.6 lab provides a safe, controlled environment where you can see the attack’s footprint in packet captures, learn how to differentiate normal traffic from malicious floods, and practice the analytical mindset required for real‑world defense.

Lab Overview

Step‑by‑Step Procedure

1. Prepare the Lab Topology

1. Deploy three VMs (or physical machines) on an isolated virtual network:

   • Attacker – will generate the flood.
   • Victim – runs a simple service (e.g., an HTTP server on port 80).
   • Monitor – runs Wireshark/tcpdump to capture all traffic on the victim’s interface.

2. Assign static IP addresses within the same subnet (e.g., 192.168.56.0/24):

   • Attacker: 192.168.56.10 - Victim: 192.168.56.20
   • Monitor: 192.168.56.30

3. Ensure the monitor’s NIC is set to promiscuous mode so it can see frames not addressed to it.

2. Baseline Capture (Optional but Helpful)

Before launching the attack, capture a few minutes of normal traffic:

sudo tcpdump -i eth0 -w baseline.pcap

Open baseline.pcap in Wireshark and note typical packet sizes, protocols, and rates. This baseline will help you spot anomalies later.

3. Launch the DDoS Flood On the attacker VM, execute a UDP flood aimed at the victim’s port 80 (or any open port):

sudo hping3 --udp --p 80 --flood --rand-source 192.168.56.20

• --udp selects UDP packets.
• --p 80 sets the destination port.
• --flood sends packets as fast as possible.
• --rand-source spoofs the source IP address for each packet, mimicking a botnet. Let the flood run for 30–60 seconds while the monitor records traffic.

4. Stop the Capture and Save the File

After the attack period, stop tcpdump (Ctrl +C) and save the capture:

sudo tcpdump -i eth0 -w ddos_attack.pcap

You now have a packet trace containing both baseline and attack traffic.

5. Initial Inspection in Wireshark

1. Open ddos_attack.pcap.

2. Apply a display filter to isolate UDP traffic:

   udp


3. Observe the packet list pane – you should see a massive surge of UDP packets directed at 192.168.56.20:80.

4. Use the Statistics → Conversations window to see the top talkers. You will likely notice:

   • A single destination IP (the victim).
   • Many different source IPs (due to --rand-source).

6. Quantitative Analysis

These numbers illustrate the volumetric nature of the attack: the goal is to exhaust the victim’s link or interface buffers rather than exploit a specific application flaw.

7. Identifying Spoofing and Reflection Clues

Even though this lab uses simple source IP randomization, real DDoS attacks often employ reflection/amplification (e.g., DNS, NTP, Memcached). To practice spotting such patterns:

1. Look for unusual source ports (e.g., 53 for DNS, 123 for NTP) in the capture.
2. Check if the payload size exceeds the typical UDP header (8 bytes) – amplification attacks carry large responses.
3. Apply a filter like udp.srcport == 53 to see if any reflection traffic appears.

In our lab, you will see mostly source port randomization with small, uniform payloads, confirming a classic UDP‑flood rather than an amplification vector. ### 8. Drafting a Mitigation Plan

Based on the observations, propose the following defensive measures:

• Ingress filtering (BCP 38) at the edge router to drop packets with spoofed source addresses not belonging to the advertised prefix.

• Rate‑limiting UDP traffic toward critical services (e.g., limit to 1 kpps per source IP).

• Blackholing or scrubbing services that can absorb and cleanse volumetric traffic before it reaches the victim.

• **

• Deploy UDP‑specific anomaly detection using NetFlow, sFlow, or IPFIX to spot sudden spikes in packets‑per‑second or bytes‑per‑second from a single destination port.

• Enable automatic black‑hole routing for destinations that exceed a configurable threshold, triggering a temporary null‑route while traffic is diverted to a scrubbing center.

• Leverage cloud‑based DDoS mitigation services that can absorb multi‑gigabit UDP floods and return only clean traffic to the origin network.

• Harden exposed UDP services (e.g., DNS, NTP) with response‑rate limiting and source‑validation techniques so they cannot be abused as reflectors even if an attacker attempts amplification.

• Conduct regular tabletop exercises and live‑fire tests using controlled traffic generators to validate that rate‑limits, ACLs, and scrubbing pipelines engage as expected before an actual event occurs.

Conclusion This lab demonstrated how a simple UDP flood with randomized source IPs can overwhelm a target link, highlighting the importance of volumetric defenses. By observing packet rates, bandwidth consumption, and source‑address diversity in Wireshark, we confirmed the attack’s reliance on sheer traffic volume rather than protocol‑specific vulnerabilities. The mitigation strategies outlined—ingress filtering, rate‑limiting, real‑time anomaly detection, black‑holing, and cloud scrubbing—form a layered approach that can detect, attenuate, and ultimately prevent such floods from reaching critical services. Continuous monitoring, periodic testing, and updating of ACLs and thresholds ensure that defenses stay effective against evolving UDP‑based DDoS tactics. Implementing these measures will significantly reduce the risk of service disruption and maintain network resilience in the face of high‑volume UDP attacks.

Building on the insights gained from this simulation, it becomes clear that the ability to detect and respond swiftly is crucial in safeguarding network integrity. As attackers increasingly exploit low-level protocols like UDP, organizations must integrate advanced monitoring tools and automated response systems to stay ahead of emerging threats. The key lies in combining technical controls with proactive training, ensuring that both staff and infrastructure can adapt to the shifting tactics of cyber adversaries.

Implementing these strategies not only mitigates the immediate impact of UDP floods but also strengthens the overall security posture of the network. By regularly reviewing traffic patterns and refining defense mechanisms, teams can transform passive monitoring into active protection. This approach empowers organizations to anticipate risks and maintain service availability even under sustained pressure.

In summary, the lab findings underscore the necessity of a multi‑layered defense, while the proposed mitigation plan offers a practical roadmap for resilience. Let’s prioritize continuous improvement in our monitoring capabilities to ensure our networks remain robust against evolving attack vectors. Concluding with this vision, the future of DDoS defense rests on our ability to adapt, learn, and act decisively.
